Insulating Coatings

1201
(Aerosol Avail. 1201A)

Red Alkyd (Brush/Spray/Dip). Bake or air dry. Meets MIL-E22118; used for coils, armatures and other electrical apparatus. Also used as a primer, sealer for screws, pipes, vacuum systems and hydraulic fluid chambers.

1201
Light Blue

Light Blue version of the 1201. Bake or air dry. Used for coils, armatures and other electrical apparatus. Also used as a primer, sealer for screws, pipes, vacuum systems and hydraulic fluid chambers.

1201
White

White version of the 1201. Bake or air dry. Used for coils, armatures and other electrical apparatus. Also used as a primer, sealer for screws, pipes, vacuum systems and hydraulic fluid chambers.

1201B

Red Alkyd (Brush/Spray/Dip. Bake or Air dry . Higher solid, higher viscosity version of 1201.

1209

Gloss Black Alkyd (Brush/Spray). Bake or air dry. Use on small motor stators, field coils, end windings, bus bars and switch bases. Also used as finishing coat on electrical equipment for interior exposure.

74004

Buff Catalyst Curing Epoxy. 74010 hardener required. Designed to give maximum durability and resistance; used on industrial equipment exposed to oils, coolants and other corrosive agents; frequently used on large end windings.

74004
red

Red version of the 74004 74010 hardener required. Designed to give maximum durability and resistance; used on industrial equipment exposed to oils, coolants and other corrosive agents; frequently used on large end windings.

7815

Gloss Black Alkyd (Brush/Spray). Bake or air dry. Used as a finishing coat on end windings and as finish coat on electrical apparatus where resistance to oil, humidity and weather is required.

C1149

ASA49 Gray Version of 74004. 74010 hardener required.

CE237

Black Alkyd (Spray/Dip). Bake or air dry. An offset to the 7815 with improved arc resistance. Designed for finishing motor end windings for oil and chemical resistance.

CE387

Blue Epoxy (Brush/Spray). Air dry. 74010 hardener required. Designed for heavy duty resistance to oil, coolants, corrosive agents to give maximum durability and chemical resistance. Used on heavy machinery, industrial equipment, interior walls, metal partitions, and laboratory areas.

Insulating Varnishes

1202

Clear General Purpose Insulating and Finishing Alkyd Varnish. Air dry. Excellent heat resistance. Up to 145C on non flexing equipment. Although primarily an air-drying varnish, the oil, moisture, acid, and salt water resistance are greatly improved by baking

9620

Clear Insulating and Finishing Varnish. Air dry. Excellent oil, moisture and acid resistance. Up to 130C on non flexing equipment. Although primarily an air-drying varnish, the oil, moisture, acid, and salt water resistance are greatly improved by baking.

Semi-Conductive Coatings

9921

Dark Green Flat Semi-Conducting Paint. Air dry. Designed for equalizing voltage stress and to prevent or decrease corona discharge.
Resistivity: 3,000-32,000 OHMS/SQ.

Harderner

74010

Epoxy Hardener. For 74004, C1149, CE387, 74121

Adhesives

880

A Thermoplastic Shellac Base Adhesive. Designed for bonding gaskets; used wherever excellent oil resistance is required, i.e., transformers, etc.

2142GN

Fast Air Drying Thermoplastic Vinyl Cement. For bonding cotton, Dacron, polyester fiber, nylon, glass tapes, laminates, slot wedges, mylar, polyester film, mica products, polyester products, vinyl products, wire enamels, paints, rayon, plastics, and metals. Has excellent resistance to oil, gasoline and moisture.

C1800

Very High Viscosity Version of 1201. For use as a quick-dry, high viscosity gasket seal and also in a variety of pipe-thread compound, gasket adhesive, vacuum system sealer, etc; does not have the electrical properties of 1201.

7526F

General Purpose Adhesive with Fungicide Resistant Properties. Its basic use is for tamper proof application over screws.

Industrial Primers-Solventborne

7920

Pearl Gray Primer (Spray). Air Dry. Designed for use on metal substrate. Fast dry, sandability, lacquer topcoat acceptance along with humidity and corrosion resistance makes this coating the ideal “shopcoat” primer.

8001

Red Oxide Primer (Spray/Dip/Flow). Bake or air dry. Excellent humidity, corrosion, and oil resistance. Adheres to phenolic and phenolic varnish films

C1149

ASA49 Catalyst Cured Epoxy. (Brush/Spray). 74010 hardener required. Used as a primer/topcoat for maximum corrosion, oil, coolant, and chemical resistance.

C1968

High Solid Gray Primer/Topcoat. (Spray). Air dry. Designed for use on metal substrates. Excellent sandability and corrosion resistance. This product can be topcoated with various lacquers and/or two package urethanes.

G7635

Red Iron Oxide Zinc Chromate Primer (Brush/Spray). Air dry. An excellent rust-inhibiting primer for metal surfaces such as transformer tanks, switchgear cabinets, machinery, etc. Should be followed by finish coat selected to suit the exposure. Interior or exterior service.

Industrial Topcoats-Solventborne

1559

White Gloss Alkyd Nitrocellulose Lacquer (Spray/Dip). Air dry. Custom finish for industrial products. Suitable for hospital and kitchen equipment. Good exterior durability with excellent gloss and color retention.

2600

Black Gloss Alkyd Nitrocellulose Lacquer (Spray/Dip). Air dry. Excellent weather durability and arc resistance. Used for electrical equipment, instruments and switchgear.

7815

Black Gloss Alkyd (Brush/Spray/Dip). Bake or Air dry. Designed as a finish coat on end windings and electrical equipment. Excellent oil, humidity and weather resistance.

8238

ASA #49 Gray Medium Gloss Vinyl Alkyd (Spray) Ready-to-Spray. Air dry. Designed for motors and equipment in the motor repair industry. Used for transformers, machines, switchgear and other electrical apparatus.

8239

ASA#61 Gray. Properties are the same as 8238 but in a #61 Gray.

8240

Forest Green. Properties are the same as 8238 but in a Forest Green.

G788

Light Gray Gloss Enamel ASA #70 (Brush/Spray) Air Dry. A durable enamel for finishing apparatus to be stored or operated outdoors. Equally suitable for interior use. May be used on metal or wood.

G1228
(Aerosol Avail. 1228A)

Dark Gray Gloss Enamel ASA #49 (Brush/Spray) Air Dry. A durable enamel for general finishing of machinery and electrical apparatus. Has excellent outdoor durability and high resistance to transformer oils. May be used on metal or wood.

G6332

Dark Green Gloss Enamel (Brush/Spray) Air Dry. A durable enamel for finishing apparatus to be stored or operated outdoors. Equally suitable for interior use. May be used on metal or wood.

G3415

Medium Gray Gloss Enamel ASA #61 (Brush/Spray) Air Dry. A durable enamel for general finishing of machinery and electrical apparatus. Has excellent outdoor durability and high resistance to transformer oils. May be used on metal or wood.

Industrial Primers-Waterborne

C1815B

Beige Waterborne Alkyd Primer (Spray). Air dry. Designed for single coat application on components subject to exterior exposure. C1815B is formulated to contain a minimum level of trace elements and is recommended for use in atomic power installations.

Chemical Resistant Coatings

74121

Red Catalyst Curing Epoxy 74010 hardener required. Air-drying epoxy enamel designed to give maximum durability and a high degree of chemical resistance Used on oil reservoirs, heavy machinery, industrial equipment, interior walls, metal partitions, and laboratory areas This product is ideally suited for all interior surfaces where maximum durability is desired and is rated as Class F

High Temperature Coatings

1212

Aluminum Gloss Alkyd Enamel (Brush/Spray). Air dry or bake. It is 1202 Glyptal varnish furnished with an aluminum paste in a two compartment container for on-the-job mixing. 1212 is suggested for finishing equipment which must stand prolonged temperatures of up to 400F It is ideally suited for the painting of steam lines, ovens, structural iron, wire fencing and exterior piping

86009

Aluminum Low Gloss Silicone (Spray/Bake). A ready mixed aluminum silicone resin product designed for high temperature applications. It provides durable protective coating on metal surfaces subjected to temperatures 400F-1200F. 86009 is suggested as a finish for ovens, jet engines and other metal surfaces needing protection during high temperature exposure. Optimum results are obtained by applying multiple thin coats (0.2-0.5 mil).

S1193

Class A & B Gray Silicone Epoxy Finish (Spray/Bake). Applications include ovens, protective finishes on jet engine components(meets GE Aircraft Engine specification number F50TF3-53) aircraft and marine surfaces, solar energy systems and high temperature automotive components. The coatings may be applied to aluminum, magnesium or steel.

S1194

Class A & B Clear Silicone Epoxy Finish (Spray/Bake). Clear version of the S1193.

S1300

Class A & B White Silicone Epoxy Finish (Spray/Bake). White version of the S1193.

S1195

Class D Resinous Reducer. Used for S1193, S1194 and S1300 Silicone epoxy.

Low VOC options are avaialable upon request for most products CustomerService@glyptal.com
